K3WA Works 160M Contests from HOA on 24' Flagpole | Greyline
Customer Spotlight · 24' DX Flagpole · HOA · 160–10M Contesting
He Had Towers and Yagis. Now He Has a 24' Flagpole. He Runs Contests at Legal Limit.
Bill K3WA is president of the Potomac Valley Radio Club — one of the most decorated contest clubs on the East Coast. He ran a full tower-and-beam station for decades. When he moved to a golf course community with deed restrictions, he didn't quit contesting. He chose a 24' Greyline DX Flagpole, put a tuner in the shack, and kept running. Including 160 meters.
Bill K3WA — PVRC President · 24' DX Flagpole
“Aside from 160, I feel that I get out much better than I had any expectation. Going from the 20 ft to the 24 ft antenna made a very big difference.”
“Now I can run in most contests both domestic and DX when condx are decent on 40 thru 10. Even on RTTY. I never expected that.”
— Bill · K3WA · PVRC President · 24' DXF · HOA Golf Course Community
160M Contest Result
61 QSOs
23 sections · ARRL CW 160M Contest · HOA lot
Operating Range
750–1,000 mi
1.8 MHz · VE3 to Florida · Illinois west
Power
Legal Limit
Flex 6600 + Power Genius Amp · 160–10M
From Tower and Beam to 24-Foot Flagpole
Bill K3WA has been active in ham radio for decades. He previously ran a serious station — tall tower, stacked Yagi antennas, the works. When he downsized to a deed-restricted golf course community, the tower went with the old house. Like a lot of operators in his position, the question wasn't whether to keep contesting. It was how.
He started with a 20' DX Flagpole and ran it hard across the bands. Then he added a 4' extension, moving to 24 feet, and noticed an immediate difference on 80 and 160 meters. He went back to contesting — domestic and DX — at legal limit on 40 through 10. Then he showed up in the ARRL CW 160M Contest results.
ARRL CW 160M Contest — December 2022 — K3WA Soapbox
"I was able to work stations as far west as Illinois and north/south from VE3 to Florida. So I did have fun!"
Band QSOs Pts Sec Cty
1.8 61 122 23 0
Total 61 122 23 0
Rig: Flex 6600, Power Genius Amp, AT-Auto antenna tuner
Antenna: 24 ft flagpole
— Bill K3WA
61 QSOs on 160 meters from an HOA lot. 23 sections across the US and Canada. 750 to 1,000 miles of effective range on 1.8 MHz with a 24-foot antenna. For context: a full-size 160M antenna is 136 feet. Bill is working that band at roughly 18% of full size — and showing up in the contest logs, 100s of them.
Bill K3WA Breaks Down His Installation
“Aside from 160, I feel that I get out much better than I had any expectation. Going from the 20 ft to the 24 ft antenna made a very big difference.
Now I can run in most contests both domestic and DX when condx are decent on 40 thru 10. Even on RTTY. I never expected that. Admittedly I do run the legal limit except on 160.
In my installation I run the twin lead to a 4:1 balun at the base and then about 60 ft coax into the shack to a tuner. I have two tuners. One is a Flex Tuner Genius which I use on 80 thru 10. For 160 I use an AT-Auto which uses a traditional coil based approach. As long as I keep my power down to 400 watts or so I don't get any arcing. The bandwidth is about 15kc so I have to retune fairly often. I get the same 160M results using an old Ameritron ATR-30 tuner.
Please do remind folks to not write off 160.”
— Bill K3WA · PVRC President · 24' DXF
Bill's Feed System — What He's Running
Feedline: Twin lead from antenna to 4:1 balun at the base, then ~60 feet of coax to the shack. This is one of the three approved Greyline feedline configurations — ladder line to shack ATU is the lowest-loss option for operators who prefer desktop tuning.
80–10M tuner: Flex Tuner Genius. Runs legal limit.
160M tuner: AT-Auto (coil-based approach) or Ameritron ATR-30. 400W maximum. 15kHz bandwidth — retune as you move across the band.
The 4:1 balun: Key to 160M performance on the 24' VDA. Transforms the impedance presented to the shack tuner into a range the coil-based tuners can handle cleanly. 1:1 Current Baluns range from $30-120 depending on power rating.
The 20' to 24' Upgrade
Bill started on the 20' DXF. He added a 4' extension and moved to 24 feet — and called it a “very big difference” on 80 and 160. The additional aperture pushes you closer to the 5/8λ sweet spot on 12 meters and meaningfully improves low-band efficiency. If you're on the fence between 20 and 24, Bill's results are the data point.
4' Extension Kit → See the 24' DXF →From Greyline Performance
Bill — 61 QSOs on 160 from an HOA lot is a result worth publishing. The twin lead to 4:1 balun to shack tuner configuration is exactly what we'd recommend for operators who want to push the low bands hard without a remote ATU at the feedpoint. The Ameritron ATR-30 confirmation is useful too — good to know that tuner gets the same result as the AT-Auto on 160. Consider this shared.
Don't write off 160. Bill's right. — Jon KL2A
